PCB H/W Design.
With 20+ years experience in electronic components industry , we're capable to develop the PCB scheme for various applications. Any inquiries, please feel free to contact us. Thank you.
AC to DC 60W PD adapter of Hight power density design
AC input range : 90~264Vac
DC output range : 5V/3A,9V/3A,12V/3A,15V/3A,20V/3A
Key Function :
1. Output: Support PD2.0 request
2. Protect: OVP/OCP/SCP/OTP
3. Safety: Meet IEC62368 request
4. PCBA dimension: 50mm(L)x50mm(W)x20mm(H)
5V+ standby of AC to DC
AC input range: 90~264Vac
DC output range: 5V/1A~3A
Key Function:
1. Output: 5Vdc±5%
2. Protect: OVP/OCP/SCP/OTP
3. Safety: Meet IEC62368 request
MCU board for function control and monitoring
DC Input: 3.3V+
Function of Control: OCP/OVP/OTP/SCP/UVP
Function of Monitoring:
1. Primary side AC Voltage/Current/Power monitoring
2. Secondary side DC Voltage/Current/Power monitoring
